Morse Cutting Tools MT1513220 A Dia. Screw Machine Drill, 135 Degrees, Black Oxide, Series/List # 2435
Short Description
Morse Cutting Tools 13220 A Dia. Screw Machine Drill, 135 Degrees, Black Oxide, Series/List # 2435
Full Description
Measurement Type
Letter
Flute Length
1-5/16″
Drill Bit Size / Cutting Diameter (DC)
A
Flute Type
Standard
Decimal Equivalent
0.2340
Overall Length (OAL)
2-7/16″
Drill Bit Size / Cutting Diameter (DC) – Letter / Wire Gauge
A
Shank Type
Round
Angle
135 Degrees
Style
Heavy Duty
Shape
Screw Machine
Point Shape
Split Point
Coating
Black Oxide
Connection Diameter Machine Side (DCONMS)
0.234″
Cutting Depth
1-5/16″
Series/List #
2435
Cutting Edge Material
HSSCo
Cobalt Screw Machine Length Drills • Heavy duty construction • 135 self-centering split point eliminates walking and reduces thrust • Short length provides maximum rigidity for increased hole accuracy and extended tool life • Cobalt steel offers increased hardness, toughness, wear resistance and heat resistance • Recommended for drilling tough, high tensile strength materials and materials that generate higher cutting temperatures including high alloy steels, ferrous castings, titanium, inconel, stainless steels and other difficult-to-drill materials
